IP Power amplifier

Power stage audio IP 2x25 W or 1x50 W stereo/mono. Ethernet. DIN rail format. All in one: IP Module + Amplifier + power supply.


Do you have questions about this product? Contact our support:



2x25 W or 1x50 W amplifier module via IP with Hi-Fi audio quality. Additional local audio inputs LINE IN and PIN input compatible with EGi products. Management for priority of announcements on environmental music. Operating modes: - Local analog inputs LINE IN and/or PIN. - Internal audio player (WAV, MP3, internet radios...). - Airplay/DLNA. - VoIP, Unicast or Multicast client. - RTP and SIP protocols. - Modbus compatible - Event scheduler. 8 GB internal memory to store audio. Updatable firmware. Configuration through web interface accessible from PC, Smartphone or Tablet. 115-230 V~ and 50/60 Hz mains power input with earth terminal block. RJ45 socket with 10/100 Mb Ethernet connection speed. Potential free output relay. Contact closure IN input that allows to launch scheduled events or activate the local audio input LINE IN. Overtemp and shorcircuit supervised. Possibility of DIN rail or surface fixing. Finish: aluminium.


Data sheet

Power Supply
Accommodation / Installation
DIN lane
Maximum consumption
80 W
Sound output power
25+25W estéreo o 50W mono
Minimum output impedance
4 Ohm estéreo ó 2 Ohm mono
Frequency response (@ -3 dB)
20 Hz - 20 KHz
Dimensions (mm)
305 x 103 x 75
Network speed
10/100 Mb
